Dn15 - Dn100 2 Way Pneumatic Solenoid Valve Stainless Steel Flange Ball Valve

Product Categories

FENGHUA FLUID AUTOMATIC CONTROL CO.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Ask Lasest Price
Brand Name :	FLUIDAC or OEM
Model Number :	BVP41-2-15-GB
Certification :	ISO9001/ISO5211
Price :	Negotiable
Payment Terms :	TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal
Supply Ability :	2000PCS per Month
Delivery Time :	Within 20 days after receiving payment or deposit

Add to Cart

DN15-DN100 2 Way Stainless Steel Pneumatic Actuated Flange Ball Valve

2 way double flange stainless steel pneumatic actuated ball valve flanged end connection.

How to order:

BV	P	4	1	2	15
Ball valve	Type: P: pneumcatic L: Lever E: Electric	Connection: 1: Female thread cnonnection 2:Male thread connection 4: Flange connection 8: Clamp type	Structure: 1: Straight bore 2:Y 3-way Y type 4:L 3-way L type 5: T 3-way T type	Tandem structure: 1: 1PCS type 2: 2PCS type 3: 3PCS type Blank: other	Norminal diemeter : 08:1/4" 10:3/8" 15:1/2" 20:3/4" 25: 1" 32: 1-1/4" 40: 1-1/2" 50: 2" 65: 2-1/2" 80: 3" 100: 4" 125: 5" 150: 6"	Valve body material: Z: CI Q: DI P: Stainless steel 304 R: Stainless steel 316 C: Carbon steel

Features:

Size	DN15~DN150
Nominal Pressure	PN1.6,2.5MPa
Stength test pressure	PT2.4~8MPa
Seal test pressure	0.6MPa
Body Material	Stainless steel(WCB.CF8.CF8M/I.Ti.Ni)
Seal Material	PTFE,PPL
Working Medium	Water,oil,gas
Working Temperature	PTFE: -20℃~+150℃
Working Temperature	PPL:-20℃~+200℃
Acting Mode	Double Acting ,Single Acting
Number of way	2 way
Application	Water&Wastewater,Textile,Food&Beverage,Chemical etc.

Specification:
