Air Source Treatment Group Filter Regulator And Lubricator For
Pneumatic Regulating System
S Series air-line service units filter regulator and
Lubricator,filter regulator,Lubricator port size PT1/4,PT3/8,PT1/2
e.g SFC-200
Quick Detail:
* S Series air service units
* Aluminum die-casting body material
* With Aluminum material bowl guard
* Modular Deisgn,different combination for flexible application
* Port size PT1/4”,PT3/8”,PT1/2”
* Pressure range adjustable 0~1.0MPa
* Filter fineness 40 Micron standard
* Stable design,pressure-resistance,long service life cycle
Applications:
S series air service units installing between the air compressor
and Pneumatic system equipment,close to pneumatic system equipment.
S series air preparation units including FR&L(Filter regulator
and Lubricator), FR(Filter Regulator), L(Lubricator)
S Series Air service units can maintain steady of the pneumatic
system pressure by air regulator,avoid the sudden change of air
source pressure to do harm to the pneumatic system components.
Filter can be clean the air source,separate the water and other
impurity from the air source,thus improve the qaulity of air medium
effectly.
Specifications:
ORDERING CODE |
SFC | 200 |
Type | Port Size |
SFC:S Series Air Units Filter Regulator and Lubricator | 200:PT1/4" |
SFR:S Series Air Units Filter Regulator | 300:PT3/8" |
SL:S Series Air Unit Lubricator | 400:PT1/2" |
SPECIFICATION
1,Working Medium:Air source
2,Body material:Aluminum die-casting
3,Filter bowl and Lubricator bowl material:PC
4,Filter element material:Brass
5,Bowl Guard:Plastic
6,Seal Material:NBR
7,Adjustabing knob:POM
8,Working pressure:0~1.0MPa
9,Working Temperature:5~60℃
10,Filtration fineness:40µ
11,Mounting type: Pipe mounting or bracket support mounting
12,Regulator type:Diaphragm type
13,Lubricator type:Oil volume adjustable during working
14,Port size:PT1/4”,PT3/8”,PT1/2”
15,Design type:Modular
Air preparation equipment units,air source treatment units,
Air-line service equipment
