0.7MPa 16mm Slide Table Air Cylinder Double Acting , Pneumatic Gas Cylinder

Ask Lasest Price
Brand Name :	FLUIDAC or OEM
Certification :	ISO9001
Model Number :	MXS-25-50
Price :	USD10--
Delivery Time :	Within 20 days after receiving payment or deposit
Payment Terms :	TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal
Supply Ability :	5000 Pieces Per month

Add to Cart

Product Details
Company Profile

0.7MPa 16mm Slide Table Air Cylinder Double Acting , Pneumatic Gas Cylinder

0.7MPa 16mm Slide Table Air Cylinder Double Acting , Pneumatic Gas Cylinder

SMC type MXS Slide table double acting Pneumatic air cylinder Bore size 6mm-25mm e.g.MXS-25-50 with cushion shock absorber

Quick Detail:

* MXS sliding table air cylinder SMC equvalent

* Double action motion pattern

* With Rubber buffer ensure smooth motion

* Integrating a cross roller bearing with a guide and two small air cylinders for compact force generation to make sure precision motion

* Available in six sizes each with set stroke lengths and is standard with auto switch capability

* Stroke adjustments are available for extend,retract or both in ranges of 0-5mm,0-15mm and 0-25mm.In addition,there are many other standard options that include shock absorbers,end lock,axial piping,and buffer

* With self-lubricating bearing,lubrication free

* Bore size 10mm,16mm,20mm,25mm

Specifications:

ORDERING CODE
MXS	25	50
MXS:Standard sliding table type	Bore Size	Stroke	Adjusting device	Functional Options
	6:6mm		Blank: No	Blank:NO
	8:8mm		AS:Front end tune-way	F:With spring buffer
	12:12mm		AT:Back-end tune-way	R:End lock
	16:16mm		A:Both ends adjusting	P:Axial connect
	20:20mm		BS:Front end shock absorber	FR:With spring buffer and End lock
	25:25mm		BT:Back end shock absorber	FP:With spring buffer and Axial connect
	25:25mm		B:Both ends shock absorber	FP:With spring buffer and Axial connect

SPECIFICATION
Bore size(mm)	6	8	12	16	20	25
Working Medium	Filtered compressed air
Motion Pattern	Double action
Operating pressure range	0.15~0.7MPa
Ambient Temperature	-10~60ºC
Operating speed	50~500mm/s
Buffer cushioning	Rubber Buffer
Port size	M3x0.5	M5x0.8	M5x0.8	M5x0.8	Rc1/8	Rc1/8

Pneumatic cylinder,Air cylinder, Linear actuator,Gas cylinder,Double shaft air cylinder,Sliding air cylinder, slide table pneumatic air cylinder.
