Aluminum Alloy 3 Way Pneumatic Mini Pedal Valve , G1/4" Pedal Foot Valve

Ask Lasest Price
Brand Name :	FLUIDAC or OEM
Certification :	ISO9001
Model Number :	PEV03S
Price :	USD5--
Delivery Time :	Within 20 days after receiving payment or deposit
Payment Terms :	TT Advance/30% deposit,70% by copy Bill oflading,Western Union,Paypal
Supply Ability :	20000 Pieces Per month

Add to Cart

Product Details
Company Profile

Aluminum Alloy 3 Way Pneumatic Mini Pedal Valve , G1/4" Pedal Foot Valve

Aluminum Alloy 3 Way Pneumatic Mini Pedal Valve , G1/4" Pedal Foot Valve
PEV series METALWORK type mini Pedal foot valve two position three way two position five way port size M5,G1/4,Ø4 e.g PEV03S spring return

Quick Detail:

* PEV series mini pedal foot valve Metalwork interchangeable
* Two position Five Way,two position three way
* Spring return reset type
* Mini Compact design,small volume easy for installation and Operating
* Smooth stroke travelling,Sensitive acting respond

Applications:

PEV series foot pedal valve manual operated use for fast direction change of anywhere and anytime necessary function required by manual operating,Due to compact volume,easy and flexible operating,it was widely use in the Pneumatic system

Specifications:

ORDERING CODE
PEV	3	3	S
Type	Port Size	Function Type	Type
PEV:METALWORK Type Mini Foot Pedal Valve	3:G1/4"	3:Two Position Three Way	S:Spring Return
	0:M5	3:Two Position Three Way
	F:Ø4	5:Two Position Five Way
	F:Ø4	5:Two Position Five Way

SPECIFICATION
Model no	PEV Series Mini Pedal Valve
Working Medium	Compressed 40 Micron Filtered Air
Body Material	Aluminum Alloy
Position And Way Numbers	Two Position Three Way Two Position-Five Way
Port Size	M5 G1/4" Ø4
Motion Pattern	Direct Acting
Working Pressure	0.25~0.9MPa
Operating Temperature	–10~60℃

Pneumatic Valve,Foot Valve,Manual Operated valve
